Pneumatic diaphragm pump is a common fluid transportation equipment, widely used in chemical, pharmaceutical, food and other industries. Correct use and maintenance can extend the service life of the Air Operated Diaphragm Pump(AODD), improve work efficiency and reduce the occurrence of failures. The following is how to use and maintain a pneumatic diaphragm pump.

How to use:

1.Pre-operation inspection: Before using the pneumatic double diaphragm pump, you need to check whether the outside of the pump is damaged or blocked by foreign matter, confirm whether the connecting pipes are loose, and ensure that the working environment is well ventilated.

2. Air source preparation: Connect the appropriate air source, and set the appropriate air pressure according to the equipment specifications and requirements, usually in the range of 0.2-0.7MPa.

3. Medium preparation: Ensure that the conveying medium meets the working requirements of the pump. For medium that is easy to crystallize or precipitate, corresponding pre-treatment measures need to be taken.

4. Start-up operation: Open the air source valve to start the pump, then adjust the air source valve to control the flow and pressure of the pump.

5. Monitor operation: After the pump starts working, it is necessary to regularly check the operating status of the pump, including parameters such as flow, pressure, temperature, etc., to ensure the normal operation of the pump.

6. Shutdown operation: When the pneumatic diaphragm pump is no longer in use, first close the air source valve, wait for the pump to stop working, and then cut off the air source.

Maintenance method:

1.Regular cleaning: According to the frequency of use, clean the pneumatic diaphragm pump regularly to remove media residue and dirt to avoid blockage and corrosion.

2. Lubrication and maintenance: Regularly lubricate and maintain key components such as the piston and valves of the pump to ensure the flexibility and sealing of the pump.

3. Seal inspection: Regularly check the seals of the diaphragm pump, such as diaphragms, sealing rings, etc., and replace damaged parts in time to ensure the sealing performance of the pump.

4. Parts inspection: Regularly check the wear of various parts, such as valves, pistons, joints, etc., and replace seriously worn parts in a timely manner to avoid malfunctions.

5. Safety valve inspection: Regularly inspect and adjust the safety valve of the pneumatic diaphragm pump to ensure that the pump can safely release pressure in the event of overpressure and prevent equipment damage and accidents.

6. Pay attention to storage: When the pneumatic diaphragm pump is not in use, store it in a dry and ventilated place to avoid moisture and corrosion.

Through correct use and maintenance methods, the stable operation and long-term reliability of the pneumatic diaphragm pump can be ensured, while repair costs and downtime are reduced, and production efficiency and safety are improved.
